500W 800W 1600W 2000W Solar Microinverter for Balcony Mounting
500W
$90.00
Skip to product information
500W 800W 1600W 2000W Solar Microinverter for Balcony Mounting
$90.00
| Product Model | HNF-050S | HNF-080S | HNF-160S | HNF-200S |
| Input Data (DC) | ||||
| Recommended PV Module Power (W) | 400~670+ | (320~540+)*2 | (320~540+)*4 | (400~670+）*4 |
| MPPT Votage Range (V) | 16 ~ 60 | |||
| Maximum Input Voltage (V) | 60 | |||
| Startup Voltage (V) | 22 | |||
| Maximum Input Current (A) | 16 | 16*2 | 14*4 | 16*4 |
| Maximum input short circuit current (ISC) (A) | 25 | |||
| Number of MPPTs | 1 | 2 | 4 | 4 |
| Output Data (AC) | ||||
| Rated Output Power (W) | 500 | 800 | 1600 | 2000 |
| Rated Output Current (A) | 2.17 | 3.48 | 6.96 | 8.7 |
| Nominal Output Voltage (V) | 220 / 230 / 240 | |||
| Nominal Output Frequency (Hz) | 50 / 60 | |||
| Power Factor (Default/Adjustable) | 0.99/0.90 leading...0.90 lagging | |||
| Total Harmonic Distortion (THDi) | ＜3% | |||
| Maximum units per branch | 16 | 6 | 3 | 2 |
| Efficiency | ||||
| Peak Efficiency | 96.70% | |||
| Dimensions (W*H*D mm) | 192*208*35 | 235*223*35 | 340*286*40.5 | 340*286*40.5 |
| Weight (kg) | 2.1 | 3.3 | 6 | 6 |
| Warranty | 12years | |||
